TAKE-E 馬達
TAKE-E MOTOR
Take-E 馬達：強勁動力、多元應用、綠能環保
- 廣泛相容性：提供多種規格，適用於登山車、城市車、摺疊車等多樣車型。
- 安裝與維護便利：設計簡潔，便於快速安裝與拆卸，升級與維修更輕鬆。
- 環保效能：透過電力驅動減少碳排放，推動永續交通模式。
Take-E 馬達為所有電動自行車愛好者帶來可靠、便利且兼顧環保的騎乘體驗。
TAKE-E MOTOR List
 |  |  |  |  |  |  | |
| Model No. | CTEM-YBE25 | CTEM-Y1C25 | CTEM-VC25 | CTEM-HC25 | CTEM-QC35 | CTEM-EC50/EC75 | CTEM-SC75 |
| Position | Rear | Rear | Rear | Rear | Rear | Rear | Rear |
| Wheel Size | 20-28 Inch | 20-28 Inch | 16-28 Inch | 16-28 Inch | 20-28 Inch | 20-28 Inch | 20-28 Inch |
| Rated Voltage | 36-48 Vdc | 36-48 Vdc | 36-48 Vdc | 36-48 Vdc | 36-48 Vdc | 36-48 Vdc | 36-48 Vdc |
| Rated Power | 250 W | 250 W | 250 W | 250~300 W | 250~300 W | 500W~750 W | 750~1200 W |
| Max Torque | ≥30 Nm | ≥30 Nm | ≥35 Nm | ≥40 Nm | ≥50 Nm | ≥90 Nm | ≥90 Nm |
| Brake | Disc-brake/V-brake | Disc-brake/V-brake | Disc-brake/V-brake | Disc-brake/V-brake | Disc-brake/V-brake | Disc-brake/V-brake | Disc-brake/V-brake |
| Installation Widths | 142mm/OLD/ thru axle Ø12mm | 142mm/OLD/ thru axle Ø12mm | 142mm/OLD | 142mm/OLD | 135mm/OLD | 142mm/OLD | 175mm/OLD |
| Cabling Route | Right | Right | Right | Right | Right | Left | Right |
| Certifications | IP54 | IP54 | IP54 | IPX5 | IP54 | IP54 | IPX5 |
| Weight | 2.1kg ±1% | 2.1kg ±1% | 2.3kg ±1% | 2.9kg ±1% | 3.5kg ±1% | 5.8kg ±1% | 5.5kg ±1% |
